4-pin industrial DC power socket
Charger: max 9.5 W / 800 mA (max battery charging current) (From batch 26)
Charger: max 4 W / 300 mA (max battery charging current) (From batch 1-25)
9 – 30 VDC
Reverse polarity protection, Overvoltage protection
9 – 30 VDC
12 VDC
3 A overcurrent protection
22 W / 1.8 A
2600 mAh 17 Wh
1x 4-pin DC connector
1x 4-pin DC connector
1x IN PWR LED, 1x OUT PWR LED, 4x Power status LEDs
On/Off slider switch
1x Active HIGH output, max output 12 V, 2.5 mA
2x 18650 Li-Ion cells
RUT2xx, RUT95x, RUT3xx, RUTXxx, TRB14x, TRB2xx, TSW110, TCR100, TRB5XX, RUTMXX, RUT90X
aluminium housing
100 x 30 x 85 mm
315g
DIN rail, wall mount, flat surface (all require additional kit)
0 °C ~ 45 °C
CE/RED, UKCA, EAC
