5 x ETH ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
Profinet Class A conformance (available with optional order code)
10 Gbps
128 KB
2K entries
9216 bytes
4-pin industrial DC power socket
9 – 30 VDC
Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 - 30 VDC
< 0.4 W/ < 1.8 W
5 x RJ45 ports, 10/100/1000 Mbps
1 x Power LED, 10 x ETH status LEDs
1 x 4-pin power connector
1 x Grounding screw
Full aluminium housing
100 x 30 x 85 mm
227 g
DIN rail, wall mount, flat surface (all require additional kit)
-40 °C to 75 °C
5% to 95% non-condensing
IP30
CE, UKCA, EAC, UCRF, ANRT, CITC, Kenya, FCC, IC, NOM, RCM, BSMI, CB
EN 55032:2015 + A11:2020
EN 61000-3-3:2013 + A1:2019
EN IEC 61000-3-2:2019
EN 55035:2017
EN 61000-4-2:2009
EN IEC 61000-4-3:2006 + A1:2008 + A2:2010
EN 61000-4-4:2012
EN 61000-4-5:2014 + A1:2017
EN 61000-4-6:2014
EN 61000-4-11:2004 + A1:2017
IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
